Carnot cycle
Internal combustion engine. Fridge
Jpornalism faculty, 209 group, Kushaliyeva Tamiris
The Carnot cycle is a theoretical thermodynamic cycle proposed by French physicist Sadi Carnot in 1824 and expanded upon by others in the 1830s and 1840s. It provides an upper limit on the efficiency that any classical thermodynamic engine can achieve during the conversion of heat into work, or conversely, the efficiency of a refrigeration system in creating a temperature difference (e.g. refrigeration) by the application of work to the system. It is not an actual thermodynamic cycle but is a theoretical construct.
Internal-combustion engine, one in which combustion of the fuel takes place in a confined space, producing expanding gases that are used directly to provide mechanical power. Such engines are classified as reciprocating or rotary, spark ignition or compression ignition, and two-stroke or four-stroke; the most familiar combination, used from automobiles to lawn mowers, is the reciprocating, spark-ignited, four-stroke gasoline engine. Other types of internal-combustion engines include the reaction engine (see jet propulsion, rocket), and the gas turbine. Engines are rated by their maximum horsepower, which is usually reached a little below the speed at which undue mechanical stresses are developed.
Reciprocating Engines
The most common internal-combustion engine is the piston-type gasoline engine used in most automobiles. The confined space in which combustion occurs is called a cylinder. The cylinders are now usually arranged in one of four ways: a single row with the centerlines of the cylinders vertical (in-line engine); a double row with the centerlines of opposite cylinders converging in a V (V-engine); a double zigzag row somewhat similar to that of the V-engine but with alternate pairs of opposite cylinders converging in two Vs (W-engine); or two horizontal, opposed rows (opposed, pancake, flat, or boxer engine). In each cylinder a piston slides up and down. One end of a connecting rod is attached to the bottom of the piston by a joint; the other end of the rod clamps around a bearing on one of the throws, or convolutions, of a crankshaft; the reciprocating (up-and-down) motions of the piston rotate the crankshaft, which is connected by suitable gearing to the drive wheels of the automobile. The number of crankshaft revolutions per minute is called the engine speed. The top of the cylinder is closed by a metal cover (called the head) bolted onto it. Into a threaded aperture in the head is screwed the spark plug, which provides ignition.
The most common internal-combustion engine is the piston-type gasoline engine used in most automobiles. The confined space in which combustion occurs is called a cylinder. The cylinders are now usually arranged in one of four ways: a single row with the centerlines of the cylinders vertical (in-line engine); a double row with the centerlines of opposite cylinders converging in a V (V-engine); a double zigzag row somewhat similar to that of the V-engine but with alternate pairs of opposite cylinders converging in two Vs (W-engine); or two horizontal, opposed rows (opposed, pancake, flat, or boxer engine). In each cylinder a piston slides up and down. One end of a connecting rod is attached to the bottom of the piston by a joint; the other end of the rod clamps around a bearing on one of the throws, or convolutions, of a crankshaft; the reciprocating (up-and-down) motions of the piston rotate the crankshaft, which is connected by suitable gearing to the drive wheels of the automobile. The number of crankshaft revolutions per minute is called the engine speed. The top of the cylinder is closed by a metal cover (called the head) bolted onto it. Into a threaded aperture in the head is screwed the spark plug, which provides ignition.
Two other openings in the cylinder are called ports. The intake port admits the air-gasoline mixture; the exhaust port lets out the products of combustion. A mushroom-shaped valve is held tightly over each port by a coil spring, and a camshaft rotating at one-half engine speed opens the valves in correct sequence. A pipe runs from each intake port to a carburetor or injector, the pipes from all the cylinders joining to form a manifold; a similar manifold connects the exhaust ports with an exhaust pipe and noise muffler. A carburetor or fuel injector mixes air with gasoline in proportions of weight varying from 11 to 1 at the richest to a little over 16 to 1 at the leanest. The composition of the mixture is regulated by the throttle, an air valve in the intake manifold that varies the flow of fuel to the combustion chambers of the cylinders. The mixture is rich at idling speed (closed throttle) and at high speeds (wide-open throttle), and is lean at medium and slow speeds (partly open throttle)
The other main type of reciprocating engine is the diesel engine, invented by Rudolf Diesel and patented in 1892. The diesel uses the heat produced by compression rather than the spark from a plug to ignite an injected mixture of air and diesel fuel (a heavier petroleum oil) instead of gasoline. Diesel engines are heavier than gasoline engines because of the extra strength required to contain the higher temperatures and compression ratios. Diesel engines are most widely used where large amounts of power are required: heavy trucks, locomotives, and ships.
Rotary Engines
The most successful rotary engine is the Wankel engine. Developed by the German engineer Felix Wankel in 1956, it has a disk that looks like a triangle with bulging sides rotating inside a cylinder shaped like a figure eight with a thick waist. Intake and exhaust are through ports in the flat sides of the cylinder. The spaces between the sides of the disk and the walls of the cylinder form combustion pockets. During a single rotation of the disk each pocket alternately grows smaller, then larger, because of the contoured outline of the cylinder. This provides for compression and expansion. The engine runs on a four-stroke cycle.
The Wankel engine has 48% fewer parts and about a third the bulk and weight of a reciprocating engine. Its main advantage is that advanced pollution control devices are easier to design for it than for the conventional piston engine. Another advantage is that higher engine speeds are made possible by rotating instead of reciprocating motion, but this advantage is partially offset by the lack of torque at low speeds, leading to greater fuel consumption.
The most successful rotary engine is the Wankel engine. Developed by the German engineer Felix Wankel in 1956, it has a disk that looks like a triangle with bulging sides rotating inside a cylinder shaped like a figure eight with a thick waist. Intake and exhaust are through ports in the flat sides of the cylinder. The spaces between the sides of the disk and the walls of the cylinder form combustion pockets. During a single rotation of the disk each pocket alternately grows smaller, then larger, because of the contoured outline of the cylinder. This provides for compression and expansion. The engine runs on a four-stroke cycle.
The Wankel engine has 48% fewer parts and about a third the bulk and weight of a reciprocating engine. Its main advantage is that advanced pollution control devices are easier to design for it than for the conventional piston engine. Another advantage is that higher engine speeds are made possible by rotating instead of reciprocating motion, but this advantage is partially offset by the lack of torque at low speeds, leading to greater fuel consumption.
The Four-Stroke Cycle
In most engines a single cycle of operation (intake, compression, power, and exhaust) takes place over four strokes of a piston, made in two engine revolutions. When an engine has more than one cylinder the cycles are evenly staggered for smooth operation, but each cylinder will go through a full cycle in any two engine revolutions. When the piston is at the top of the cylinder at the beginning of the intake stroke, the intake valve opens and the descending piston draws in the air-fuel mixture.
At the bottom of the stroke the intake valve closes and the piston starts upward on the compression stroke, during which it squeezes the air-fuel mixture into a small space at the top of the cylinder. The ratio of the volume of the cylinder when the piston is at the bottom to the volume when the piston is at the top is called the compression ratio. The higher the compression ratio, the more powerful the engine and the higher its efficiency. However, in order to accommodate air pollution control devices, manufacturers have had to lower compression ratios.
Just before the piston reaches the top again, the spark plug fires, igniting the air-fuel mixture (alternatively, the heat of compression ignites the mixture). The mixture on burning becomes a hot, expanding gas forcing the piston down on its power stroke. Burning should be smooth and controlled. Faster, uncontrolled burning sometimes occurs when hot spots in the cylinder preignite the mixture; these explosions are called engine knock and cause loss of power. As the piston reaches the bottom, the exhaust valve opens, allowing the piston to force the combustion products—mainly carbon dioxide, carbon monoxide, nitrogen oxides, and unburned hydrocarbons—out of the cylinder during the upward exhaust stroke.
At the bottom of the stroke the intake valve closes and the piston starts upward on the compression stroke, during which it squeezes the air-fuel mixture into a small space at the top of the cylinder. The ratio of the volume of the cylinder when the piston is at the bottom to the volume when the piston is at the top is called the compression ratio. The higher the compression ratio, the more powerful the engine and the higher its efficiency. However, in order to accommodate air pollution control devices, manufacturers have had to lower compression ratios.
Just before the piston reaches the top again, the spark plug fires, igniting the air-fuel mixture (alternatively, the heat of compression ignites the mixture). The mixture on burning becomes a hot, expanding gas forcing the piston down on its power stroke. Burning should be smooth and controlled. Faster, uncontrolled burning sometimes occurs when hot spots in the cylinder preignite the mixture; these explosions are called engine knock and cause loss of power. As the piston reaches the bottom, the exhaust valve opens, allowing the piston to force the combustion products—mainly carbon dioxide, carbon monoxide, nitrogen oxides, and unburned hydrocarbons—out of the cylinder during the upward exhaust stroke.
The Second Law of Thermodynamics essentially states that if a cold object is placed next to a hot object, the cold object will become warmer and the hot object will become cooler. A refrigerator does not cool items by lowering their original temperatures; instead, an evaporating gas called a refrigerant draws heat away, leaving the surrounding area much colder. Refrigerators and air conditioners both work on the principle of cooling through evaporation.
A refrigerator consists of two storage compartments - one for frozen items and the other for items requiring refrigeration but not freezing. These compartments are surrounded by a series of heat-exchanging pipes. Near the bottom of the refrigerator unit is a heavy metal device called a compressor. The compressor is powered by an electric motor. More heat-exchanging pipes are coiled behind the refrigerator. Running through the entire system is pure ammonia, which evaporates at -27 degrees Fahrenheit (-32 Celsius). This system is closed, which means nothing is lost or added while it is operating. Because liquid ammonia is a powerful chemical, a leaking refrigerator should be repaired or replaced immediately.
The refrigeration process begins with the compressor. Ammonia gas is compressed until it becomes very hot from the increased pressure. This heated gas flows through the coils behind the refrigerator, which allow excess heat to be released into the surrounding air. This is why users sometimes feel warm air circulating around the fridge. Eventually the ammonia cools down to the point where it becomes a liquid. This liquid form of ammonia is then forced through a device called an expansion valve. Essentially, the expansion valve has such a small opening that the liquid ammonia is turned into a very cold, fast-moving mist, evaporating as it travels through the coils in the freezer. Since this evaporation occurs at -27 degrees F (-32 degrees Celsius), the ammonia draws heat from the surrounding area. This is the Second Law of Thermodynamics in effect. Cold material, such as the evaporating ammonia gas, tend to take heat from warmer materials, such as the water in the ice cube tray.
As the evaporating ammonia gas absorbs more heat, its temperature rises. Coils surrounding the lower refrigerator compartment are not as compact. The cool ammonia still draws heat from the warmer objects in the fridge, but not as much as the freezer section. The ammonia gas is drawn back into the compressor, where the entire cycle of pressurization, cooling and evaporation begins anew.
As the evaporating ammonia gas absorbs more heat, its temperature rises. Coils surrounding the lower refrigerator compartment are not as compact. The cool ammonia still draws heat from the warmer objects in the fridge, but not as much as the freezer section. The ammonia gas is drawn back into the compressor, where the entire cycle of pressurization, cooling and evaporation begins anew.
